Frame: full 4130 crmo, tapered SS and CS, with removable brake pivots & guides
Fork: SALTPLUS "REASON” fork, full 4130 crmo , butted crmo steerer, 22mm offset
Bars: SALTPLUS "HQ" 4pc" full 4130 crmo bar
Grips: WETHEPEOPLE "Remote” flangeless grips, super soft rubber
Stem: SALT "ZION” top loading stem, 50mm reach
Headset: SALT "PRO” int. headset, sealed bearing
Gyro: holes for removable gyro tabs
Lever: SALT "AM” alloy brake lever
Brakes: ÉCLAT "TALON" alloy u-brake-rear
Cranks: SALT "REVO” square profile, 3pc 4130 crmo, 165mm, 8 spline
BB: SALT "MID” 19mm, press fit, sealed bearing
Pedals: WETHEPEOPLE "LOGIC”, nylon/fiberglass pedals
Chain: SALT "AM” chain, Z1 type
Sprocket SALTPLUS "SOLIDUS” CNC machined 6061-T6 alloy, 25t sprocket
Driver: 9t, 1pc freecoaster driver, sealed bearing, RSD
Front Hub: SALT "PRO” hub, sealed bearing, 3/8”s axle, 36h
Rear Hub: SALT "PRO" freecoaster hub, full sealed, 9t, 14mm axle, 36h, RSD
Hubguards: SALT "PRO" Nylon/Fibreglass hubguards x4
Front Rim: SALT "VALON” 36mm single wall rim, 36h
Rear Rim: SALTPLUS "SUMMIT” 36mm double wall rim, 36h
Seat: ECLAT "BIOS" fat padded Pivotal seat
Seat Post: SALT "AM" Pivotal seat post
Seat Clamp: integrated seat clamp
Tires: SALTPLUS "Burn” 2.35" front & rear
Pegs: SALT "AM" steel pegs (x2), 4.15" long
Weight: 12.53kg / 27.63lbs - without brakes, with pegs
FRAME GEOMETRY
A: Top Tube Length: 20.75”
B: Chain Stay Length: 12.75”
C: Head Tube Angle: 76°
D: Seat Tube Angle: 71°
E: Bottom Bracket Height: 11.75”
F: Stand Over Height: 9”
BAR GEOMETRY
G: Bar Rise: 9"
H: Bar Width: 29.1”
I: Bar Back Sweep: 11°
J: Bar Up Sweep: 3°
