FRAME: Kink Williams Stock 100% 4130 Chromoly Double Butted TT/DT
FORK: Kink Origin 1.5pc CNC Steerer Tube 100% 4130 Chromoly Butted Tapered Legs
BARS: Kink Williams 4pc 9.25" 100% 4130 Chromoly 13-Butted TruTherm Heat Treated
GRIPS: Kink Form, Thrust Barends
STEM: Cinema Martinez 48mm CNC 6061-T6
HEADSET: Mission Sealed Integrated (41.8 x 45)
BRAKE LEVER: Mission Token
BRAKE CABLE: Mission L4 Linear
BRAKES: Mission Cease V2 (Removable Mounts)
CRANKS: Kink Ridge 3pc Tubular Chromoly 165mm – 8 Spline
BOTTOM BRACKET: Sealed Mid 19mm
PEGS: 4 x Cinema C4 Pegs
PEDALS: Cinema CK Pedals
CHAIN: Cinema Sync Half-Link
SPROCKET: Cinema Beta 25T 6061-T6 Guard Sprocket
SEAT: Cinema Standard Stealth
SEAT POST: Cinema Stealth 3D Forged
SEAT CLAMP: Integrated
FRONT HUB: Cinema Pilot Sealed Bolt-in Hub w/Guards
REAR HUB: Cinema Pilot Sealed Freecoaster 14mm w/Guards
DRIVER: 9T
RIMS: Cinema 444
TIRES: Cinema Williams 2.5"
WEIGHT: 12700 g
Toptube Length | 21" |
Chainstay Length | 12.75" |
Headtube Angle | 75.5° |
Seattube Angle | 71° |
Standover Height | 9″ |
Bottom Bracket Height | 11.7" |
Fork Offset | 30mm |
